BGPPL Imperial C2S Art Board

BGPPL Imperial C2S Art Board

Features
  • Double Blade Coated product with properties at par with other international brands in this segment.
  • Smooth surface enabling better print coverage.
  • Available in the range of 180 to 350 gsm in reels and sheets.
  • Can be supplied with PEFC Certification(PEFC/42-31-02).
End Usages

Calendars, Book Covers, Greeting Cards, Folders, Catalogues & other Commercial printing jobs.

Contact Us
Specifications
PROPERTIES   UNIT Test Method Reference 180 190 200 210 220 230 250 300 350 Tolerence
GRAMMAGE   gsm T-410 om-93 180 190 200 210 220 230 250 300 350 AVG±2.5%
BULK   cc/gm T-411 om-89 0.84 0.85 0.86 0.87 0.88 0.88 0.95 0.95 0.95 ±0.03
BENDING STIFFNESS MD Taber T-836 pm-95 10 12 13 18 20 25 40 60 95 Min.
50mm, 15º angle CD Taber   6 8 9 10 11 15 30 35 54 Min.
BREAKING LENGTH MD meter T-494 om-88 3200 3200 3200 3200 3200 3200 3200 3200 3200 ±500
  CD meter   2000 2000 2000 2000 2000 2000 2000 2000 2000 ±500
ISO BRIGHTNESS T/B % T-452 om-92 87 87 87 87 87 87 87 87 87 ±1
ISO OPACITY   % T-452 om-91 99 99 99 99 99 99 99 99 99 ±2
ISO GLOSS at 75° T/B % T-480 om-92 70 70 70 70 70 70 70 70 65 ±5
PARKER PRINT SURF T/B µ T-555 pm-94 1.25 1.25 1.25 1.25 1.25 1.25 1.50 1.50 1.50 Max.
IGT PICK (MVO) T/B cm/sec T-514 cm-92 110 110 110 110 110 110 110 110 110 Min.
SURFACE pH T/B - T-529 om-88 7 - 8 7 - 8 7 - 8 7 - 8 7 - 8 7 - 8 7 - 8 7 - 8 7 - 8 -
PROPERTIES   UNIT Test Method Reference 180 190 200 210 220 230 250 300 350 Tolerence
GRAMMAGE   gsm T-410 om-93 180 190 200 210 220 230 250 300 350 AVG±2.5%
BULK   cc/gm T-411 om-89 0.96 0.96 0.96 0.97 0.98 1.00 1.00 1.00 1.00 ±0.03
BENDING STIFFNESS MD Taber T-836 pm-95 12 15 20 24 30 33 45 75 110 Min.
50mm, 15º angle CD Taber   6 8 10 13 15 18 25 45 65 Min.
BREAKING LENGTH MD meter T-494 om-88 3200 3200 3200 3200 3200 3200 3200 3200 3200 ±500
  CD meter   2000 2000 2000 2000 2000 2000 2000 2000 2000 ±500
ISO BRIGHTNESS T/B % T-452 om-92 88 88 88 88 88 88 88 88 88 ±1
ISO OPACITY   % T-452 om-91 99 99 99 99 99 99 99 99 99 ±2
ISO GLOSS at 75° T/B % T-480 om-92 33 33 33 33 33 33 33 33 33 ±5
PARKER PRINT SURF T/B µ T-555 pm-94 2.50 2.50 2.50 2.50 2.50 2.50 2.50 2.50 2.50 Max.
IGT PICK (MVO) T/B cm/sec T-514 cm-92 110 110 110 110 110 110 110 110 110 Min.
SURFACE pH T/B - T-529 om-88 7 - 8 7 - 8 7 - 8 7 - 8 7 - 8 7 - 8 7 - 8 7 - 8 7 - 8
